Coilover 24-Way Suspension Kit for Mitsubishi Lancer 02-06 Adjust Damper Coilover Suspension Shocks

Applications
for Mitsubishi Lancer/Mirage (CS6A /CS7A) FWD 2002-2006

Specifications

1.4PCS of Coilovers (2 piece front + 2 pieces rear)

2.24-way adjustable damper force

3.Front Spring Rate:  7kg/mm  (392 lbs/in)

4.Rear Spring Rate: 6kg/mm  (336lbs/in)

5.Height adjustable:Front:430-515m;Rear:360-395mm

6.Camber Plate adjustable :YES（only front）

7.spring Preload: 7-10 mm

8.shock type：Twin tube

9.Warranty: 2 year

10.daily driver, occasional autocross day or occasional track days，Equally at home on street and track

11.For those seeking a lowered stance as well as improved handling and response at a high value

12.Package size and  weight ：71*52*22cm        25.4kg

Feature

1.camber plate top mounts help to  eliminate the need for a separate camber kit

2.Pillow ball top mount — this design helps combat noise while tuning. It also improves the steering feel and response

3.Rubber top mounts front and rear help to deliver a smooth and forgiving ride for city use at any speed, and rubber joints assist in absorbing hard impacts.

4.Height adjustable:Front:430-515m;Rear:360-395mm，  allow you have more aggressive stance

5.24 levels of damping rebound adjustment allow you to perfectly dial in your coilover system for both handling and comfort

6.separate height adjustment without sacrifice of damper stroke & without removing the coilover out from the car

dust boot included to protect damper seal

7.Twin-Tube Structure – For Low Resiliency & Securing Sufficient Stroke

8.High Tensile performance spring – Under 600,000 times continuously test, the spring distortion is less than 0.04%. 9.Plus, the special surface treatment is to improve the durability and performance.

10.Most pieces in our Coilover systems, including mounts, collars and spring perches, are designed from 6061-T6 11.Billet Aluminum resulting in lightweight, durable and rust resistant components.

12.Steel shock bodies are electroplated with Zinc  for anti Anti-corrosion

13.full rebuildable

Notice

* No instruction included; Professional installation & alignment suggested.
